مقالات ویدئو پروژکتور پاناسونیک
معرفی و توضیح انواع ویدئو پروژکتورهای پاناسونیک
مقالات ویدئو پروژکتور پاناسونیک
معرفی و توضیح انواع ویدئو پروژکتورهای پاناسونیکویدئوپروژکتور پاناسونیک PT-RZ470
ویدئوپروژکتور پاناسونیک PT-RZ470
Panel Type 0.65" DLP x 1
Lamp N.A. (LED/laser-combined light source)
Brightness 3,500 lumens
Lens F2.0-3.4, f21.5-43mm
Contrast (Full on / Full off) 20000:1
Resolution (Native / maximum) Full HD (1920x1080)
Video Compatibility PAL, PAL-M, PAL-N, PAL60, SECAM, NTSC, NTSC4.43
Screen Size 40" - 300"
Lens Shift Vertical +73%, -48%, horizontal +27%, -35%
Keystone Correction Range Vertical ±40°
Weight 11kg
Dimensions (W x H x D) 455 x 137 x 415 mm
Power Consumption 460W
Terminals HDMI (19-pin x 2)
DVI-D (29-pin x 1)
PC (D-sub HD 15-pin x 1)
Composite video (RCA x 1)
Audio in (M3 (L-R) x 1)
Audio out (M3 (L-R) x 1)
Serial (D-sub 9-pin x 1)
LAN/ Digital Link (RJ-45 x 1)
ایران پاناسونیک
آدرس سایت:WWW.IRANPANASONIC.IR
تماس:7761510
ویدئوپروژکتور پاناسونیک PT-LX351
ویدئوپروژکتور پاناسونیک PT-LX351
Panel Type 0.55" DLP x 1
Lamp 240W x 1
Brightness 3,500 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.5kg
Dimensions (W x H x D) 286 x 100 x 230 mm
Power Consumption 320W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 2)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (D-sub 9-pin(female)x1)
Audio in (M3 x 2)
Audio out (M3 x 1 (L-R x 1)
LAN (RJ-45 x 1)
Replacement Lamp ET-LAL340
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S
(Low ceiling mount bracket) ET-PKL300B (Bracket assembly)Panel Type 0.55" DLP x 1
Lamp 240W x 1
Brightness 3,500 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.5kg
Dimensions (W x H x D) 286 x 100 x 230 mm
Power Consumption 320W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 2)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (D-sub 9-pin(female)x1)
Audio in (M3 x 2)
Audio out (M3 x 1 (L-R x 1)
LAN (RJ-45 x 1)
Replacement Lamp ET-LAL340
ایران پاناسونیک
آدرس سایت:WWW.IRANPANASONIC.IR
تماس:7761510
ویدئوپروژکتور پاناسونیک PT-LX300
ویدئوپروژکتور پاناسونیک PT-LX300
Panel Type 0.55" DLP x 1Lamp 190W x 1
Brightness 3,000 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.3kg
Dimensions (W x H x D) 286 x 100.6 x 192 mm
Power Consumption 218W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 1)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (Mini DIN 3-pin (female) x 1)
Audio in (M3 x 1)
Audio out (M3 x 1 (L-R x 1)
Replacement Lamp ET-LAL320
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S (Low ceiling mount bracket) ET-PKL300B (Bracket assembly)
Standard Accessories Wireless remote control unit Battery Power cord VGA cable
ایران پاناسونیک
آدرس سایت:WWW.IRANPANASONIC.IR
تماس:77615100
ویدئوپروژکتور پاناسونیک PT-LX271
ویدئوپروژکتور پاناسونیک PT-LX271
Panel Type 0.55" DLP x 1
Lamp 190W x 1
Brightness 2,700 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.5kg
Dimensions (W x H x D) 286 x 100 x 230 mm
Power Consumption 260W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 2)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (D-sub 9-pin(female)x1)
Audio in (M3 x 2)
Audio out (M3 x 1 (L-R x 1)
LAN (RJ-45 x 1)
Replacement Lamp ET-LAL330
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S (Low ceiling mount bracket) ET-PKL300B (Bracket assembly)
Standard Accessories Wireless remote control unit Battery Power cord VGA cable
ایران پاناسونیک
Panel Type 0.55" DLP x 1
Lamp 190W x 1
Brightness 2,700 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.5kg
Dimensions (W x H x D) 286 x 100 x 230 mm
Power Consumption 260W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 2)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (D-sub 9-pin(female)x1)
Audio in (M3 x 2)
Audio out (M3 x 1 (L-R x 1)
LAN (RJ-45 x 1)
Replacement Lamp ET-LAL330
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S (Low ceiling mount bracket) ET-PKL300B (Bracket assembly)
Standard Accessories Wireless remote control unit Battery Power cord VGA cable
ایران پاناسونیک
آدرس سایت:WWW.IRANPANASONIC.IR
تماس:77615100
ویدئوپروژکتور پاناسونیک PT-LX270
ویدئوپروژکتور پاناسونیک PT-LX270
Panel Type 0.55" DLP x 1
Lamp 190W x 1
Brightness 2,700 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.3kg
Dimensions (W x H x D) 286 x 100.6 x 192 mm
Power Consumption 218W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 1)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (Mini DIN 3-pin (female) x 1)
Audio in (M3 x 1)
Audio out (M3 x 1 (L-R x 1)
Replacement Lamp ET-LAL320
Panel Type 0.55" DLP x 1
Lamp 190W x 1
Brightness 2,700 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.3kg
Dimensions (W x H x D) 286 x 100.6 x 192 mm
Power Consumption 218W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 1)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (Mini DIN 3-pin (female) x 1)
Audio in (M3 x 1)
Audio out (M3 x 1 (L-R x 1)
Replacement Lamp ET-LAL320
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S
(Low ceiling mount bracket) ET-PKL300B (Bracket assembly)
ایران پاناسونیک
آدرس سایت:WWW.IRANPANASONIC.IR
تماس:77615100
